6V 4A76 4LR44 4AG13 L1325 Alkaline Battery 145mAh Dog Training Shock Collar Car Alarm Remote
Description:
The 6V Alkaline Battery is worked in Dog Training Shock Collar, car alarm remote and other .And it has a low power consumption and is energy-saving. With no pollution, no infrared and no thermal radiation, It is also easy to install, affordable, and a high quality Battery!
Equivalent to:4LR44P, 4SR44, 4G13, 4NZ13, 4034PX,28, 28A, 28L,PX28A, PX28L,PX28AB,K28A, K28L, V28PXL,28PX, V34PX, V4034PX,1406SOP, 1406LC, 2CR1/3N, 2CR11108, A544, L544, 7H34,L1325, 1414A
Applications:
Electric shock stop barking,beauty pen,AE1 camera,remote control,electronic scales,electronic toys,computers,game consoles,anti-bark collar,laser pointer and an alarm clock, Dog Training Shock Collar Cameras, Car Alarm Remote and other equipment.
Specifications:
| Nominal Voltage | 6V |
| Nominal Capacity (Continuous Discharging Under 1kΩ load to 3.6V End-Voltage at 20℃) | 145mAh |
| Operating temperature range | -20℃~70℃ |
 | A(ref.) | 1.10-0.15 |
| B | 25.60-25.80 |
| C | 12.17-12.20 |
| D(ref.) | 0.30-0.45 |
| Mass | Approx 9.97g |
| Open-circuit Voltage | 6V-6.2V |
| Appearance and poles | Appearance should be smooth, clear mark, no deformation, rust, and leakage |
| Minimum Average Discharge Time(1kΩ) | Initial test (New battery) | 25h |
| After 12 months | 23h |
| Leakage Characteristics (Over discharge) | No Leakage |
Discharge Curve:(Condition: Continuous Discharging Under 1kΩ load to 3.6V End-Voltage at 20℃)
Competitive Advantage:
1) Environmental friendly,Light weight
2) High density of energy
3) Low self-discharge
4) Low internal resistance
5) No memory effect
6) Free of mercury
7) Safety assurance : No fire, No explosion, No leakage
Tag:High Voltage battery,alkaline battery
